cluster_feasibility_filter.c File Reference

#include <assert.h>
#include "read_xml_arch_file.h"
#include "util.h"
#include "vpr_types.h"
#include "globals.h"
#include "hash.h"
#include "cluster_feasibility_filter.h"
#include "vpr_utils.h"
#include "ReadOptions.h"

Include dependency graph for cluster_feasibility_filter.c:

Go to the source code of this file.

Functions
static void	alloc_pin_classes_in_pb_graph_node (INOUTP t_pb_graph_node *pb_graph_node)
static int	get_max_depth_of_pb_graph_node (INP t_pb_graph_node *pb_graph_node)
static void	load_pin_class_by_depth (INOUTP t_pb_graph_node *pb_graph_node, INP int depth, OUTP int *input_count, OUTP int *output_count)
static void	load_list_of_connectable_input_pin_ptrs (INOUTP t_pb_graph_node *pb_graph_node)
static void	expand_pb_graph_node_and_load_output_to_input_connections (INOUTP t_pb_graph_pin *current_pb_graph_pin, INOUTP t_pb_graph_pin *reference_pin, INP int depth)
static void	unmark_fanout_intermediate_nodes (INOUTP t_pb_graph_pin *current_pb_graph_pin)
static void	reset_pin_class_scratch_pad_rec (INOUTP t_pb_graph_node *pb_graph_node)
static void	expand_pb_graph_node_and_load_pin_class_by_depth (INOUTP t_pb_graph_pin *current_pb_graph_pin, INP t_pb_graph_pin *reference_pb_graph_pin, INP int depth, OUTP int *input_count, OUTP int *output_count)
static void	sum_pin_class (INOUTP t_pb_graph_node *pb_graph_node)
static void	discover_all_forced_connections (INOUTP t_pb_graph_node *pb_graph_node)
static boolean	is_forced_connection (INP t_pb_graph_pin *pb_graph_pin)
void	load_pin_classes_in_pb_graph_head (INOUTP t_pb_graph_node *pb_graph_node)

Function Documentation

static void alloc_pin_classes_in_pb_graph_node ( INOUTP t_pb_graph_node *  pb_graph_node )

static

Recursive function to allocate memory space for pin classes in primitives

Definition at line 85 of file cluster_feasibility_filter.c.

                                               {
    int i, j, k;

    /* If primitive, allocate space, else go to primitive */
    if (pb_graph_node->pb_type->num_modes == 0) {
        /* allocate space */
        for (i = 0; i < pb_graph_node->num_input_ports; i++) {
            for (j = 0; j < pb_graph_node->num_input_pins[i]; j++) {
                pb_graph_node->input_pins[i][j].parent_pin_class =
                        (int *) my_calloc(pb_graph_node->pb_type->depth,
                                sizeof(int*));
                for (k = 0; k < pb_graph_node->pb_type->depth; k++) {
                    pb_graph_node->input_pins[i][j].parent_pin_class[k] = OPEN;
                }
            }
        }
        for (i = 0; i < pb_graph_node->num_output_ports; i++) {
            for (j = 0; j < pb_graph_node->num_output_pins[i]; j++) {
                pb_graph_node->output_pins[i][j].parent_pin_class =
                        (int *) my_calloc(pb_graph_node->pb_type->depth,
                                sizeof(int*));
                pb_graph_node->output_pins[i][j].list_of_connectable_input_pin_ptrs =
                        (t_pb_graph_pin ***) my_calloc(
                                pb_graph_node->pb_type->depth,
                                sizeof(t_pb_graph_pin**));
                pb_graph_node->output_pins[i][j].num_connectable_primtive_input_pins =
                        (int*) my_calloc(pb_graph_node->pb_type->depth,
                                sizeof(int));
                for (k = 0; k < pb_graph_node->pb_type->depth; k++) {
                    pb_graph_node->output_pins[i][j].parent_pin_class[k] = OPEN;
                }
            }
        }
        for (i = 0; i < pb_graph_node->num_clock_ports; i++) {
            for (j = 0; j < pb_graph_node->num_clock_pins[i]; j++) {
                pb_graph_node->clock_pins[i][j].parent_pin_class =
                        (int *) my_calloc(pb_graph_node->pb_type->depth,
                                sizeof(int*));
                for (k = 0; k < pb_graph_node->pb_type->depth; k++) {
                    pb_graph_node->clock_pins[i][j].parent_pin_class[k] = OPEN;
                }
            }
        }
    } else {
        for (i = 0; i < pb_graph_node->pb_type->num_modes; i++) {
            for (j = 0;
                    j < pb_graph_node->pb_type->modes[i].num_pb_type_children;
                    j++) {
                for (k = 0;
                        k
                                < pb_graph_node->pb_type->modes[i].pb_type_children[j].num_pb;
                        k++) {
                    alloc_pin_classes_in_pb_graph_node(
                            &pb_graph_node->child_pb_graph_nodes[i][j][k]);
                }
            }
        }
    }
}

Here is the call graph for this function:

Here is the caller graph for this function:

static void discover_all_forced_connections ( INOUTP t_pb_graph_node *  pb_graph_node )

static

Definition at line 545 of file cluster_feasibility_filter.c.

                                                                                   {
    int i, j, k;

    /* If primitive, allocate space, else go to primitive */
    if (pb_graph_node->pb_type->num_modes == 0) {
        for(i = 0; i < pb_graph_node->num_output_ports; i++) {
            for(j = 0; j < pb_graph_node->num_output_pins[i]; j++) {
                pb_graph_node->output_pins[i][j].is_forced_connection = is_forced_connection(&pb_graph_node->output_pins[i][j]);
            }
        }
    } else {
        for (i = 0; i < pb_graph_node->pb_type->num_modes; i++) {
            for (j = 0;
                    j < pb_graph_node->pb_type->modes[i].num_pb_type_children;
                    j++) {
                for (k = 0;
                        k < pb_graph_node->pb_type->modes[i].pb_type_children[j].num_pb;
                        k++) {
                    discover_all_forced_connections(&pb_graph_node->child_pb_graph_nodes[i][j][k]);
                }
            }
        }
    }
}

Here is the call graph for this function:

Here is the caller graph for this function:

static void expand_pb_graph_node_and_load_output_to_input_connections ( INOUTP t_pb_graph_pin *  current_pb_graph_pin, INOUTP t_pb_graph_pin *  reference_pin, INP int  depth  )

static

Definition at line 346 of file cluster_feasibility_filter.c.

                                                             {
    int i;

    if (current_pb_graph_pin->scratch_pad == OPEN
            && current_pb_graph_pin->parent_node->pb_type->depth > depth) {
        current_pb_graph_pin->scratch_pad = 1;
        for (i = 0; i < current_pb_graph_pin->num_output_edges; i++) {
            assert(current_pb_graph_pin->output_edges[i]->num_output_pins == 1);
            expand_pb_graph_node_and_load_output_to_input_connections(
                    current_pb_graph_pin->output_edges[i]->output_pins[0],
                    reference_pin, depth);
        }
        if (current_pb_graph_pin->parent_node->pb_type->num_modes == 0
                && current_pb_graph_pin->port->type == IN_PORT) {
            reference_pin->num_connectable_primtive_input_pins[depth]++;
            reference_pin->list_of_connectable_input_pin_ptrs[depth] =
                    (t_pb_graph_pin**) my_realloc(
                            reference_pin->list_of_connectable_input_pin_ptrs[depth],
                            reference_pin->num_connectable_primtive_input_pins[depth]
                                    * sizeof(t_pb_graph_pin*));
            reference_pin->list_of_connectable_input_pin_ptrs[depth][reference_pin->num_connectable_primtive_input_pins[depth]
                    - 1] = current_pb_graph_pin;
        }
    }
}

Here is the call graph for this function:

Here is the caller graph for this function:

static void expand_pb_graph_node_and_load_pin_class_by_depth ( INOUTP t_pb_graph_pin *  current_pb_graph_pin, INP t_pb_graph_pin *  reference_pb_graph_pin, INP int  depth, OUTP int *  input_count, OUTP int *  output_count  )

static

Determine other primitive pins that belong to the same pin class as reference pin

Definition at line 393 of file cluster_feasibility_filter.c.

                                                       {
    int i;
    int marker;
    int active_pin_class;

    if (reference_pb_graph_pin->port->type == IN_PORT) {
        marker = *input_count + 10;
        active_pin_class = *input_count;
    } else {
        marker = -10 - *output_count;
        active_pin_class = *output_count;
    }
    assert(reference_pb_graph_pin->parent_node->pb_type->num_modes == 0);
    assert(current_pb_graph_pin->parent_node->pb_type->depth >= depth);
    assert(current_pb_graph_pin->port->type != INOUT_PORT);
    if (current_pb_graph_pin->scratch_pad != marker) {
        if (current_pb_graph_pin->parent_node->pb_type->num_modes == 0) {
            current_pb_graph_pin->scratch_pad = marker;
            /* This is a primitive, determine what pins cans share the same pin class as the reference pin */
            if (current_pb_graph_pin->parent_pin_class[depth] == OPEN
                    && reference_pb_graph_pin->port->is_clock
                            == current_pb_graph_pin->port->is_clock
                    && reference_pb_graph_pin->port->type
                            == current_pb_graph_pin->port->type) {
                current_pb_graph_pin->parent_pin_class[depth] =
                        active_pin_class;
            }
            for (i = 0; i < current_pb_graph_pin->num_input_edges; i++) {
                assert(
                        current_pb_graph_pin->input_edges[i]->num_input_pins == 1);
                expand_pb_graph_node_and_load_pin_class_by_depth(
                        current_pb_graph_pin->input_edges[i]->input_pins[0],
                        reference_pb_graph_pin, depth, input_count,
                        output_count);
            }
            for (i = 0; i < current_pb_graph_pin->num_output_edges; i++) {
                assert(
                        current_pb_graph_pin->output_edges[i]->num_output_pins == 1);
                expand_pb_graph_node_and_load_pin_class_by_depth(
                        current_pb_graph_pin->output_edges[i]->output_pins[0],
                        reference_pb_graph_pin, depth, input_count,
                        output_count);
            }
        } else if (current_pb_graph_pin->parent_node->pb_type->depth == depth) {
            current_pb_graph_pin->scratch_pad = marker;
            if (current_pb_graph_pin->port->type == OUT_PORT) {
                if (reference_pb_graph_pin->port->type == OUT_PORT) {
                    /* This cluster's output pin can be driven by primitive outputs belonging to this pin class */
                    current_pb_graph_pin->pin_class = active_pin_class;
                }
                for (i = 0; i < current_pb_graph_pin->num_input_edges; i++) {
                    assert(
                            current_pb_graph_pin->input_edges[i]->num_input_pins == 1);
                    expand_pb_graph_node_and_load_pin_class_by_depth(
                            current_pb_graph_pin->input_edges[i]->input_pins[0],
                            reference_pb_graph_pin, depth, input_count,
                            output_count);
                }
            }
            if (current_pb_graph_pin->port->type == IN_PORT) {
                if (reference_pb_graph_pin->port->type == IN_PORT) {
                    /* This cluster's input pin can drive the primitive input pins belonging to this pin class */
                    current_pb_graph_pin->pin_class = active_pin_class;
                }
                for (i = 0; i < current_pb_graph_pin->num_output_edges; i++) {
                    assert(
                            current_pb_graph_pin->output_edges[i]->num_output_pins == 1);
                    expand_pb_graph_node_and_load_pin_class_by_depth(
                            current_pb_graph_pin->output_edges[i]->output_pins[0],
                            reference_pb_graph_pin, depth, input_count,
                            output_count);
                }
            }
        } else if (current_pb_graph_pin->parent_node->pb_type->depth > depth) {
            /* Inside an intermediate cluster, traverse to either a primitive or to the cluster we're interested in populating */
            current_pb_graph_pin->scratch_pad = marker;
            for (i = 0; i < current_pb_graph_pin->num_input_edges; i++) {
                assert(
                        current_pb_graph_pin->input_edges[i]->num_input_pins == 1);
                expand_pb_graph_node_and_load_pin_class_by_depth(
                        current_pb_graph_pin->input_edges[i]->input_pins[0],
                        reference_pb_graph_pin, depth, input_count,
                        output_count);
            }
            for (i = 0; i < current_pb_graph_pin->num_output_edges; i++) {
                assert(
                        current_pb_graph_pin->output_edges[i]->num_output_pins == 1);
                expand_pb_graph_node_and_load_pin_class_by_depth(
                        current_pb_graph_pin->output_edges[i]->output_pins[0],
                        reference_pb_graph_pin, depth, input_count,
                        output_count);
            }
        }
    }
}

Here is the caller graph for this function:

static int get_max_depth_of_pb_graph_node ( INP t_pb_graph_node *  pb_graph_node )

static

Definition at line 147 of file cluster_feasibility_filter.c.

                                                                              {
    int i, j, k;
    int max_depth, depth;

    max_depth = 0;

    /* If primitive, allocate space, else go to primitive */
    if (pb_graph_node->pb_type->num_modes == 0) {
        return pb_graph_node->pb_type->depth;
    } else {
        for (i = 0; i < pb_graph_node->pb_type->num_modes; i++) {
            for (j = 0;
                    j < pb_graph_node->pb_type->modes[i].num_pb_type_children;
                    j++) {
                for (k = 0;
                        k
                                < pb_graph_node->pb_type->modes[i].pb_type_children[j].num_pb;
                        k++) {
                    depth = get_max_depth_of_pb_graph_node(
                            &pb_graph_node->child_pb_graph_nodes[i][j][k]);
                    if (depth > max_depth) {
                        max_depth = depth;
                    }
                }
            }
        }
    }

    return max_depth;
}

Here is the caller graph for this function:

static boolean is_forced_connection ( INP t_pb_graph_pin *  pb_graph_pin )

static

Given an output pin, determine if it connects to only one input pin and nothing else.

Definition at line 573 of file cluster_feasibility_filter.c.

                                                                      {
    if(pb_graph_pin->num_output_edges > 1) {
        return FALSE;
    }
    if(pb_graph_pin->num_output_edges == 0) {
        if(pb_graph_pin->parent_node->pb_type->num_modes == 0) {
            /* Check that this pin belongs to a primitive */
            return TRUE;
        } else {
            return FALSE;
        }
    }
    return is_forced_connection(pb_graph_pin->output_edges[0]->output_pins[0]);
}

Here is the caller graph for this function:

static void load_list_of_connectable_input_pin_ptrs ( INOUTP t_pb_graph_node *  pb_graph_node )

static

Load internal output-to-input connections within each cluster

Definition at line 312 of file cluster_feasibility_filter.c.

                                               {
    int i, j, k;

    if (pb_graph_node->pb_type->num_modes == 0) {
        /* If this is a primitive, discover what input pins the output pins can connect to */
        for (i = 0; i < pb_graph_node->num_output_ports; i++) {
            for (j = 0; j < pb_graph_node->num_output_pins[i]; j++) {
                for (k = 0; k < pb_graph_node->pb_type->depth; k++) {
                    expand_pb_graph_node_and_load_output_to_input_connections(
                            &pb_graph_node->output_pins[i][j],
                            &pb_graph_node->output_pins[i][j], k);
                    unmark_fanout_intermediate_nodes(
                            &pb_graph_node->output_pins[i][j]);
                }
            }
        }
    }
    /* Expand down to primitives */
    for (i = 0; i < pb_graph_node->pb_type->num_modes; i++) {
        for (j = 0; j < pb_graph_node->pb_type->modes[i].num_pb_type_children;
                j++) {
            for (k = 0;k < pb_graph_node->pb_type->modes[i].pb_type_children[j].num_pb;
                    k++) {
                load_list_of_connectable_input_pin_ptrs(
                        &pb_graph_node->child_pb_graph_nodes[i][j][k]);
            }
        }
    }
}

Here is the call graph for this function:

Here is the caller graph for this function:

static void load_pin_class_by_depth ( INOUTP t_pb_graph_node *  pb_graph_node, INP int  depth, OUTP int *  input_count, OUTP int *  output_count  )

static

Definition at line 213 of file cluster_feasibility_filter.c.

                                                                      {
    int i, j, k;

    if (pb_graph_node->pb_type->num_modes == 0) {
        if (pb_graph_node->pb_type->depth > depth) {
            /* At primitive, determine which pin class each of its pins belong to */
            for (i = 0; i < pb_graph_node->num_input_ports; i++) {
                for (j = 0; j < pb_graph_node->num_input_pins[i]; j++) {
                    if (pb_graph_node->input_pins[i][j].parent_pin_class[depth]
                            == OPEN) {
                        expand_pb_graph_node_and_load_pin_class_by_depth(
                                &pb_graph_node->input_pins[i][j],
                                &pb_graph_node->input_pins[i][j], depth,
                                input_count, output_count);
                        (*input_count)++;
                    }
                }
            }
            for (i = 0; i < pb_graph_node->num_output_ports; i++) {
                for (j = 0; j < pb_graph_node->num_output_pins[i]; j++) {
                    if (pb_graph_node->output_pins[i][j].parent_pin_class[depth]
                            == OPEN) {
                        expand_pb_graph_node_and_load_pin_class_by_depth(
                                &pb_graph_node->output_pins[i][j],
                                &pb_graph_node->output_pins[i][j], depth,
                                input_count, output_count);
                        (*output_count)++;
                    }
                }
            }
            for (i = 0; i < pb_graph_node->num_clock_ports; i++) {
                for (j = 0; j < pb_graph_node->num_clock_pins[i]; j++) {
                    if (pb_graph_node->clock_pins[i][j].parent_pin_class[depth]
                            == OPEN) {
                        expand_pb_graph_node_and_load_pin_class_by_depth(
                                &pb_graph_node->clock_pins[i][j],
                                &pb_graph_node->clock_pins[i][j], depth,
                                input_count, output_count);
                        (*input_count)++;
                    }
                }
            }
        }
    }

    if (pb_graph_node->pb_type->depth == depth) {
        /* Load pin classes for all pb_graph_nodes of this depth, therefore, at a particular pb_graph_node of this depth, set # of pin classes to be 0 */
        *input_count = 0;
        *output_count = 0;
        for (i = 0; i < pb_graph_node->num_input_ports; i++) {
            for (j = 0; j < pb_graph_node->num_input_pins[i]; j++) {
                pb_graph_node->input_pins[i][j].pin_class = OPEN;
            }
        }
        for (i = 0; i < pb_graph_node->num_output_ports; i++) {
            for (j = 0; j < pb_graph_node->num_output_pins[i]; j++) {
                pb_graph_node->output_pins[i][j].pin_class = OPEN;
            }
        }
        for (i = 0; i < pb_graph_node->num_clock_ports; i++) {
            for (j = 0; j < pb_graph_node->num_clock_pins[i]; j++) {
                pb_graph_node->clock_pins[i][j].pin_class = OPEN;
            }
        }
    }

    /* Expand down to primitives */
    for (i = 0; i < pb_graph_node->pb_type->num_modes; i++) {
        for (j = 0; j < pb_graph_node->pb_type->modes[i].num_pb_type_children;
                j++) {
            for (k = 0;
                    k
                            < pb_graph_node->pb_type->modes[i].pb_type_children[j].num_pb;
                    k++) {
                load_pin_class_by_depth(
                        &pb_graph_node->child_pb_graph_nodes[i][j][k], depth,
                        input_count, output_count);
            }
        }
    }

    if (pb_graph_node->pb_type->depth == depth
            && pb_graph_node->pb_type->num_modes != 0) {
        /* Record pin class information for cluster */
        pb_graph_node->num_input_pin_class = *input_count + 1; /* number of input pin classes discovered + 1 for primitive inputs not reachable from cluster input pins */
        pb_graph_node->input_pin_class_size = (int*) my_calloc(*input_count + 1,
                sizeof(int));
        pb_graph_node->num_output_pin_class = *output_count + 1; /* number of output pin classes discovered + 1 for primitive inputs not reachable from cluster input pins */
        pb_graph_node->output_pin_class_size = (int*) my_calloc(*output_count + 1,
                sizeof(int));
        sum_pin_class(pb_graph_node);
    }

}

Here is the call graph for this function:

Here is the caller graph for this function:

void load_pin_classes_in_pb_graph_head

(

INOUTP t_pb_graph_node *

pb_graph_node

)

Definition at line 62 of file cluster_feasibility_filter.c.

                                                                              {
    int i, depth, input_count, output_count;

    /* Allocate memory for primitives */
    alloc_pin_classes_in_pb_graph_node(pb_graph_node);

    /* Load pin classes */
    depth = get_max_depth_of_pb_graph_node(pb_graph_node);
    for (i = 0; i < depth; i++) {
        input_count = output_count = 0;
        reset_pin_class_scratch_pad_rec(pb_graph_node);
        load_pin_class_by_depth(pb_graph_node, i, &input_count, &output_count);
    }

    /* Load internal output-to-input connections within each cluster */
    reset_pin_class_scratch_pad_rec(pb_graph_node);
    load_list_of_connectable_input_pin_ptrs(pb_graph_node);
    discover_all_forced_connections(pb_graph_node);
}

Here is the call graph for this function:

Here is the caller graph for this function:

static void reset_pin_class_scratch_pad_rec ( INOUTP t_pb_graph_node *  pb_graph_node )

static

Definition at line 178 of file cluster_feasibility_filter.c.

                                               {
    int i, j, k;

    for (i = 0; i < pb_graph_node->num_input_ports; i++) {
        for (j = 0; j < pb_graph_node->num_input_pins[i]; j++) {
            pb_graph_node->input_pins[i][j].scratch_pad = OPEN;
        }
    }
    for (i = 0; i < pb_graph_node->num_output_ports; i++) {
        for (j = 0; j < pb_graph_node->num_output_pins[i]; j++) {
            pb_graph_node->output_pins[i][j].scratch_pad = OPEN;
        }
    }
    for (i = 0; i < pb_graph_node->num_clock_ports; i++) {
        for (j = 0; j < pb_graph_node->num_clock_pins[i]; j++) {
            pb_graph_node->clock_pins[i][j].scratch_pad = OPEN;
        }
    }

    for (i = 0; i < pb_graph_node->pb_type->num_modes; i++) {
        for (j = 0; j < pb_graph_node->pb_type->modes[i].num_pb_type_children;
                j++) {
            for (k = 0;
                    k
                            < pb_graph_node->pb_type->modes[i].pb_type_children[j].num_pb;
                    k++) {
                reset_pin_class_scratch_pad_rec(
                        &pb_graph_node->child_pb_graph_nodes[i][j][k]);
            }
        }
    }
}

Here is the caller graph for this function:

static void sum_pin_class ( INOUTP t_pb_graph_node *  pb_graph_node )

static

Definition at line 493 of file cluster_feasibility_filter.c.

                                                                 {
    int i, j;

    /* This is a primitive, for each pin in primitive, sum appropriate pin class */
    for (i = 0; i < pb_graph_node->num_input_ports; i++) {
        for (j = 0; j < pb_graph_node->num_input_pins[i]; j++) {
            assert(
                    pb_graph_node->input_pins[i][j].pin_class < pb_graph_node->num_input_pin_class);
            if (pb_graph_node->input_pins[i][j].pin_class == OPEN) {
                vpr_printf(TIO_MESSAGE_WARNING, "%s[%d].%s[%d] unconnected pin in architecture.\n",
                        pb_graph_node->pb_type->name,
                        pb_graph_node->placement_index,
                        pb_graph_node->input_pins[i][j].port->name,
                        pb_graph_node->input_pins[i][j].pin_number);
                continue;
            }
            pb_graph_node->input_pin_class_size[pb_graph_node->input_pins[i][j].pin_class]++;
        }
    }
    for (i = 0; i < pb_graph_node->num_output_ports; i++) {
        for (j = 0; j < pb_graph_node->num_output_pins[i]; j++) {
            assert(
                    pb_graph_node->output_pins[i][j].pin_class < pb_graph_node->num_output_pin_class);
            if (pb_graph_node->output_pins[i][j].pin_class == OPEN) {
                vpr_printf(TIO_MESSAGE_WARNING, "%s[%d].%s[%d] unconnected pin in architecture.\n",
                        pb_graph_node->pb_type->name,
                        pb_graph_node->placement_index,
                        pb_graph_node->output_pins[i][j].port->name,
                        pb_graph_node->output_pins[i][j].pin_number);
                continue;
            }
            pb_graph_node->output_pin_class_size[pb_graph_node->output_pins[i][j].pin_class]++;
        }
    }
    for (i = 0; i < pb_graph_node->num_clock_ports; i++) {
        for (j = 0; j < pb_graph_node->num_clock_pins[i]; j++) {
            assert(
                    pb_graph_node->clock_pins[i][j].pin_class < pb_graph_node->num_input_pin_class);
            if (pb_graph_node->clock_pins[i][j].pin_class == OPEN) {
                vpr_printf(TIO_MESSAGE_WARNING, "%s[%d].%s[%d] unconnected pin in architecture.\n",
                        pb_graph_node->pb_type->name,
                        pb_graph_node->placement_index,
                        pb_graph_node->clock_pins[i][j].port->name,
                        pb_graph_node->clock_pins[i][j].pin_number);
                continue;
            }
            pb_graph_node->input_pin_class_size[pb_graph_node->clock_pins[i][j].pin_class]++;
        }
    }
}

Here is the caller graph for this function:

static void unmark_fanout_intermediate_nodes ( INOUTP t_pb_graph_pin *  current_pb_graph_pin )

static

Clear scratch_pad for all fanout of pin

Definition at line 377 of file cluster_feasibility_filter.c.

                                                     {
    int i;
    if (current_pb_graph_pin->scratch_pad != OPEN) {
        current_pb_graph_pin->scratch_pad = OPEN;
        for (i = 0; i < current_pb_graph_pin->num_output_edges; i++) {
            assert(current_pb_graph_pin->output_edges[i]->num_output_pins == 1);
            unmark_fanout_intermediate_nodes(
                    current_pb_graph_pin->output_edges[i]->output_pins[0]);
        }
    }
}

Here is the caller graph for this function:
